CATEGORY
FERRYDimensions
41.50 x 08.00 x 02.40 meters
Machinery
2 Unit @ 405 Yanmar Engine 6 HA2M-DTE 1950 rpm
Build
New Build
Status
10 months Lead Time
Description
Download Technical Drawing
Download Drawing 1
Code of Vessel |
: LCT 37 M Passenger |
Type of Vessel |
: Steel Landing Craft Tank |
Classification |
: BKI |
Build |
: New Build |
Length Over All ( LOA ) |
: 41.50 meters |
Registered Breadth |
: 08.00 meters |
Registered Depth |
: 02.40 meters |
GT |
: 325 GT |
|
|
Machinery |
|
Main Engine |
: 2 units 405 HP Yanmar Engine 6 HA2M-DTE 1950 rpm |
Gearbox |
: 2 units Gear Box HC 135 A HangZhou, Ratio 1:5 |
Generator |
: 2 units Yanmar Model 4TNE 98-GIA 1500-1800 rpm |
OWS |
: 1 unit Zhenziang type CYF 0.25 |
Water Pump |
: 1 unit Panasonic GBE 125 |
Pump |
: 2 units Ebara Pump 2”+Dynamo 5,5 HP, 4 kw |
Anchor |
: 2 units @ 300 Kg |
Winch Anchor |
: Electric Motor |
Chain Anchor |
: 6 Length size ¾, left 3 Length, right 3 length |
Steer |
: Hydraulic manual |
Rope |
: 2 rolls @50 m size: 2” |
Door (Ramp door) |
: Electric Motor |
|
|
Safety |
|
Landing buoy |
: 8 pcs Type xt 5555 (720x440) |
Lightlanding buoy |
: 2 pcs |
Life graft |
: 4 units 25 Persons |
Life Jacket |
: 85 pcs |
Fire extinguisher |
: 7 pcs portable water 9 kg |
|
: 2 pcs portable CO2 3 kg |
|
: 3 pcs portable CO2 7 kg |
|
: 2 pcs foam 9 kg |
First aid kit |
: 1 pc |
Smoke signal |
: 1 pc |
Parachute signal |
: 3 pcs |
Red hand flare |
: 3 pcs |
Bell |
: 1 pc |
Horn |
: 1 pc |
Siren |
: 1 pc |
Fire Hose |
: 9 sets size 2”x 30 meter |
Nozzle |
: 9 pcs size 2” |
Flag |
: 1 pc Indonesian flag |
Automatic liferaft |
: 4 sets types Hammar |
|
|
Navigation |
|
Satellite |
: 1 unit Garmin GPS MAP-420IPC GPS Maping +Sounder GA 29 |
Compass magnetic |
: 1 unit Daiko T-150, 6” |
Radar |
: 1 unit Furuno 1715 MK II |
Binoculars |
: 1 pc type Bosma |
Clear view screen |
: 1 pc 24 volt, 10’ |
Search light |
: 1 pc CTG – 3, 1,000 Watt |
Clinometers |
: 1 pc |
|
|
Communication Equipment |
|
Power supply |
1 unit type PS 130 |
Radio |
1 unit icom M-710 s/n 4102112 |
|
20 meters Belden RG-8 Coaxial cable USA |
|
35 meters AWG-24 Cabel power 9 lines |
|
2 units Amphenol PL-259 UHF-m |
|
1 unit icom AT-130 Automatic tuner M-710 s/n 81275 |
|
3 units icon V-80 HT |
|
2 units ACR Telluasart MK-3 |
|
|
Accommodation |
|
Air condition |
: 6 sets AC LG 2PK |
|
: 3 sets AC LG 1 PK |
Televise |
: 1 unit 21’ LG |
Bed crew |
: 11 pcs pillow + bed sheet |
Refrigerator |
: 1 pc refrigerator type 2 doors type GN-V212SLT |
Clock |
: 2 pcs |
Freezer 100 Ltr |
: 1 unit Type Changhong BD-155 |
